GYTC 8S Type Duplex Fiber Optical Cable 8 Optical Cable Corrosion Resistant
Product Details:
| Place of Origin: | Dongguan |
| Brand Name: | HAOKAI |
| Certification: | ROHS/ISO/UL/SGS |
| Model Number: | GYTC 8S |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10000m |
|---|---|
| Price: | By negotiation |
| Packaging Details: | Wooden/Pellet |
| Delivery Time: | 1-5work days |
| Payment Terms: | T/T, Western Union, MoneyGram, L/C |
| Supply Ability: | 100000m/1day |
|
Detail Information |
|||
| Steel Wire: | 0.8mm | Keyword: | Outdoor Fiber Optic Cable |
|---|---|---|---|
| Sample: | Free | Core: | 4～144 |
| Jacket Material: | PE (Polyethylene), LSZH (Low Smoke Zero Halogen), PVC (Polyvinyl Chloride) | Number Of Conductor: | ≥ 10 |
| Loose Tube Material: | PBT | Standard Structure: | Central Loose Tube |
| High Light: | GYTC 8S Fiber Optical Cable,Corrosion Resistant Duplex Fiber Cable,Duplex Fiber 8 Optical Cable |
||
Product Description
GYTC 8S Type -8 Optical Cable
Product application
● Duplex fiber movable connection jumper or pigtail
● Indoor shaft level and forced ventilation level wiring
● Interconnection of instruments and communication equipment
Product characteristics
● Uses tight-sleeved optical fibers for easy stripping and use.
● Tight-clad optical fiber has good flame retardant performance
● Aramid reinforced elements make optical cables have excellent tensile properties.
● The 8-shaped structure sheath is easy to peel off the branches for use.
● External protection materials have the advantages of corrosion resistance, waterproof, UV protection, flame retardant, environmental protection, etc.
Cable Parameters
| Fiber Model | Tube.No. | Steel stranded wire Dia. mm |
Cable OD. mm | Weight kg/km | Tensile resistance Long/short term N |
Crush resistance Long/short term N/100mm |
| GYTC8S-2~36Xn | 5 | 3.0 | 9.2×6×16.5 | 150 | 3000/8000 | 300/1000 |
| GYTC8S-48~60Xn | 5 | 3.0 | 9.5×6×17 | 180 | 3000/8000 | 300/1000 |
| GYTC8S-64~72Xn | 6 | 3.0 | 10.5×6×19 | 200 | 3000/8000 | 300/1000 |
| GYTC8S-96Xn | 8 | 3.0 | 12.5×6×21 | 260 | 3000/8000 | 300/1000 |
| GYTC8S-122~144Xn | 12 | 3.0 | 14.5×6×24.5 | 350 | 3000/8000 | 300/1000 |
