LSZH / PVC FTTH Indoor Cable 1000m 2000m GJFJBV Fiber Optic Cable

LSZH / PVC FTTH Indoor Cable 1000m 2000m GJFJBV Fiber Optic Cable

Product Details:

Place of Origin: Dongguan
Brand Name: HAOKAI
Certification: ROHS/ISO/UL/SGS
Model Number: GJFJBV

Payment & Shipping Terms:

Minimum Order Quantity: 10000m
Price: By negotiation
Packaging Details: Wooden/Pellet
Delivery Time: 1-5work days
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 100000m/1day
Get Best Price Contact Now

Detail Information

Length: 1000m/2000m Material: LSZH/PVC
High Light:

PVC FTTH Indoor Cable

,

LSZH FTTH Indoor Cable

,

GJFJBV Fiber Optic Cable

Product Description

FTTH Indoor Cable GJFJBV Fiber Optic Cable



Product Descripition

GJFJBV Duplex cable use single 900um or 600um tight buffer fiber as optical communication medium , the tight buffer fiber wrapped with a layer of aramid yarn as strength member units, and the cable is completed with a PVC or LSZH (low smoke ,Zero halogen, Flame-retardant ) jacket.



Product application
● Optical fiber jumper or pigtail.
Indoor riser level and plenum level cable distribution.
● Interconnect between instruments, communication equipment.


Product characteristics

Tight buffer fiber easy of stripping.
Tight buffer fiber have excellent flame-retardant performance.
● Aramid yarn as strength member makes cable have excellent tensile strength.
The jacket anti-corrosion, anti-water, anti-ultraviolet radiation, flame-retardant and harmless to environment etc.






Cable Parameters

 Fiber Model    Cable code mm Tight buffer diameter mm  Weight(KG) storage temperature(℃)  Tensile resistance
  Long/short term
N
  Crush resistance
     Long/short term      N/100mm
GJFJBV-1Xn (1.55-1.65)*(3.20*3.60) 0.6 5.8 40 160/80 500/100
GJFJBV-2Xn (1.70-1.80)*(3.60*4.20) 0.6 7.3 40 160/80 500/100
GJFJBV-4Xn (1.80-2.00)*(3.90*4.30) 0.9 8.8 40 200/100 1000/200
GJFJBV-6Xn (2.30-2.45)*(4.60*5.00) 0.9 9.9 40 200/100 1000/200
GJFJBV-8Xn (2.68-2.85)*(5.30*5.80) 0.9 13.5 40 300/160 1000/200
